P Types

• Designed for Direct Current Loads and compatible with modern electronic control systems, suitable for use in applications such as motors used on small winches.
• Developed for both interrupted and uninterrupted loads, the DC64P is suitable for switching Resistive, Capacitive and Inductive loads.
• Monoblock construction and sealed to IP66 thus offering greater protection against adverse environments such as water or dust.
• M6 main stud terminals and coil connections are by means of 6.3mm spades.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Direct Current loads and compatible with modern electronic control systems, suitable for use in applications such as battery powered winches, vehicle mounted cranes and small electric vehicles.
• Developed for Interrupted and Uninterrupted applications, and suited for switching Inductive, Resistive and Capacitive loads.
• Monoblock construction and sealed to IP67 offering greater protection against adverse environments such as water or dust and allowing for water immersion up to 1 metre.
• Devised for motor reversing, the main contact circuit has a built in fail safe, so that if both coils are energised simultaneously the contact arrangement is open circuit.
• M6 main stud terminals and 6.3mm spades coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the DC88-1000P Type is suitable for switching Resistive, Capacitive and Inductive loads.
• Monoblock construction and sealed to IP67 offering greater protection against adverse environments such as water or dust, and allowing for water immersion up to 1 metre.
• Devised for motor reversing, the main contact circuit has a built in fail safe, so that if both coils are energised simultaneously the contact arrangement is open circuit.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the DC88P is suitable for switching Resistive, Capacitive and Inductive loads.
• Sealed to IP66 thus offering greater protection against adverse environments such as water or dust.
• M8 main stud terminals and coil connections are by means of 6.3mm spades.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

View Product

• Designed for direct current loads, typical applications include motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the DC92P is suitable for switching Resistive, Capacitive and Inductive loads.
• Devised for motor reversing, the main contact circuit has a built in fail safe, so that if both coils are energised simultaneously the contact arrangement is open circuit
• Monoblock construction and sealed to IP66 thus offering greater protection against adverse environments such as water or dust.
• M8 stud main terminals and 6.3mm spade coil connections.

• Designed for direct current loads, particularly motors as used on electric winches, a monoblock construction it is compatible with modern electronic control systems.
• Developed for both interrupted and uninterrupted loads, the DC88P is suitable for switching Resistive, Capacitive and Inductive loads.
• The main contact circuit, designed for motor reversing, has a built in failsafe, so that if both coils are energised simultaneously the circuit remains open.
• Sealed to IP67 thus offering greater protection against adverse environments such as water or dust.
• M8 main stud terminals and coil connections are by means of 6.3mm spades.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed to fill the gap between 30 Ampere relays and 80 Ampere contactors, typical applications are small traction motors, hydraulic power packs and engine starter motors for golf cars and garden machinery.
• Developed for both interrupted and uninterrupted loads, the MC50 is suitable for switching Resistive and Inductive loads up to 48V DC.
• Offers environmental protection to IP67.
• M8 stud main terminals with the option of M6, and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for printed circuit board mounting used within applications such as Telecommunication, UPS and other power conversion systems..
• Devised for both interrupted and uninterrupted loads, the PC6oP is suitable for switching Resistive, Capacitive and Inductive loads.
• Offers environmental protection to IP66.
• Secured to the printed circuit board by means of an M4 bolt.

Note: The PC range now incorporates the mounting board option, previously assigned to the MB range (existing MB part numbers remain valid).

• Designed for printed circuit board mounting and used within applications such as Telecommunication, UPS and other power conversion systems.
• Devised for both interrupted and uninterrupted loads, the PC61P is suitable for switching Resistive, Capacitive and Inductive loads.
• Offers environmental protection to IP66.
• Secured to the printed circuit board by means of an M4 bolt.

Note: The PC range now incorporates the mounting board option, previously assigned to the MB range (existing MB part numbers remain valid).

• Designed for printed circuit board mounting and used within applications such as Telecommunication, UPS and other power conversion systems.
• Devised for both interrupted and uninterrupted loads, the PC63P is suitable for switching Resistive, Capacitive and Inductive loads.
• Offers environmental protection to IP66.
• Secured to the printed circuit board by means of an M4 bolt.

Note: The PC range now incorporates the mounting board option, previously assigned to the MB range (existing MB part numbers remain valid).

• Designed for Direct Current Loads where where infrequent switching is specified, typical applications include in line contactors and Power Distribution Systems.
• Developed for Uninterrupted current loads the RU80 is suitable for switching Resistive, Capacitive and Inductive loads.
• Sealed to IP66 thus offering greater protection against adverse environments such as water or dust.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Direct Current Loads where where infrequent switching is specified, typical applications include in line contactors and Power Distribution Systems.
• Developed for Uninterrupted current loads the RU280P is suitable for switching Resistive, Capacitive and Inductive loads.
• Sealed to IP66 thus offering greater protection against adverse environments such as water or dust.
• M10 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Direct Current loads, typical applications include switching small traction motors, hydraulic power packs and small electric winch motors.
• Developed for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Direct Current loads, typical applications include, but are not limited to, electric motors, hydraulic power packs, winches, speed controllers, UPS and Power Distribution Systems.
• Developed for both interrupted and uninterrupted loads, the SU80P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

View Product

• Designed for direct current loads, typical applications include motors as used on electronic vehicles such as industrial trucks and airport tractors.
• Developed for both interrupted and uninterrupted loads, the SU280P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M10 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Direct Current loads, particularly motors as used on electronic vehicles such as industrial trucks and airport tractors.
• Developed for both interrupted and uninterrupted loads, the SU400P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M10 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations)

Compliant with EN1175:2020

• Designed for direct current loads, typical applications include switching small traction motors, hydraulic power packs and small electric winch motors.
• Developed for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed to fill the gap between 30 ampere relays and 100 ampere contactors, typical applications include switching small traction motors, hydraulic power packs and small electric winch motors.
• Devised for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed to fill the gap between 30 ampere relays and 100 ampere contactors, typical applications include switching small traction motors, hydraulic power packs and small electric winch motors.
• Devised for both interrupted and uninterrupted loads, the SW64P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed to fill the gap between 30 ampere relays and 100 ampere contactors, typical applications include switching small traction motors, hydraulic power packs and small electric winch motors.
• Devised for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
•  Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for direct current loads in more arduous environments, typical applications include winches and motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the SW80P is suitable for switching Resistive, Capacitive and Inductive loads.
• Enclosed top cover and offers environmental protection to IP66.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for direct current loads, including motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the SW82P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for direct current loads, typical applications include motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, the SW85P is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

Please note normally closed contacts are not designed to make and break load.

• Designed for Motor Reversing applications with direct current loads, typical applications include motors as used on small traction motors, hydraulic power packs and small electric winch motors.
• Developed for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M6 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).

• Designed for Motor Reversing applications with direct current loads, typical applications include motors as used on electric vehicles such as industrial trucks.
• Developed for both interrupted and uninterrupted loads, it is suitable for switching Resistive, Capacitive and Inductive loads.
• Incorporates an enclosed top cover and offers environmental protection to IP66.
• M8 stud main terminals and 6.3mm spade coil connections.
• Adaptable Mounting options, in any orientation (seek technical advice for full mounting considerations).
